HITROL HT-100RT - Specifications

HT-100R Series
HITROL CO., LTD. 4
Specifications STAINLESS STEEL
Model
HT-100RS
HT-100RSH
HT-100RS-Ex
HT-100RSH-Ex
Mounting
Flange
Process Temperature
Max. 80℃
Max. 150℃
Max. 80℃
Max. 150℃
Process Pressure
Up to 20kg/cm2(300#)
Power Source
DC +24V
Output
DC 4~20mA(2~wire)
Enclosure
Weather-Proof (IP65)
Ex-Proof (Ex d IIC T6)
Ex-Proof (Ex d IIC T4)
Wetted Part Material
SUS304, SUS316L
Process Connection
100A JIS 10K
Housing
PC, AL.(Opt.)
AL.
Cable Entry
PF 3/4”(F), Adaptor (PF 1/2”, NPT 3/4”…)
Resolution & Accuracy
±10mm
PVC
Model
HT-100RV
HT-100RV-Ex
Mounting
Flange
Process Temperature
Max. 60℃
Process Pressure
Up to 0.5kg/cm2
Power Source
DC +24V
Output
DC 4~20mA(2~wire)
Enclosure
Weather-Proof (IP65)
Ex-Proof (Ex d IIC T6)
Wetted Part Material
PVC
Process Connection
100A JIS 10K FF
Housing
PC, AL.(Opt.)
AL.
Cable Entry
PF 3/4”(F), Adaptor (PF 1/2”, NPT 3/4”…)
Resolution & Accuracy
±10mm
TEFLON
Model
HT-100RT
HT-100RTH
HT-100RT-Ex
HT-100RTH-Ex
Mounting
Flange
Process Temperature
Max. 80℃
Max. 150℃
Max. 80℃
Max. 150℃
Process Pressure
Up to 0.5~3kg/cm2
Power Source
DC +24V
Output
DC 4~20mA(2~wire)
Enclosure
Weather-Proof (IP65)
Ex-Proof (Ex d IIC T6)
Ex-Proof (Ex d IIC T4)
Wetted Part Material
SUS304+TEFLON, SUS316L+TEFLON
Process Connection
100A JIS 10K
Housing
PC, AL.(Opt.)
AL.
Cable Entry
PF 3/4”(F), Adaptor (PF 1/2”, NPT 3/4”…)
Resolution & Accuracy
±10mm
