HITROL HT-100RT - Float Application

HT-100R Series
HITROL CO., LTD. 5
Above application can be different according to the specific gravity and the specific medium
Float
Application
Note: ◎ = Excellent ○ = Good △ = Acceptable X = Not good
M-100R
Float
Environment
Temperature
(℃)
Pressure
(㎏/㎠)
Acid
Alkaline
Oil
Solvent
Liquid gas
SUS 316L
-20 ~ +150
Up to 20
△
○
○
◎
△
PVC
-10 ~ +60
0.5
○
○
X
△
X
TEFLON
-20 ~ +150
0.5~3
◎
◎
X
○
△
NBR
-48 ~ +60
Up to 20
X
△
◎
△
○
TITANIUM
-20 ~ +150
Up to 10
X
△
◎
○
○
Item
Specifications
Microprocessor
16Bit Microprocessor
Current Loop Interface
2-Wire Loop Current
Supply Voltage
+17V ~ +40V @ Typ.+24V
Operating Voltage
+3.3V
Output Current Accuracy
3.8mA ~ 20.5mA @ ±0.2% F.S
Output Current Range
3.8mA ~ 20.5mA @ Alarm 3.6mA, 21mA [NAMUR NE43]
Output Current Offset
■ Zero: 3.9 ~ 4.1mA
■ Span: 19.9 ~ 20.1mA
±0.1mA @ 0.01mA Step
Output Current Definite
TP
Damping Time
0.5 sec @ Fixed
Self-Diagnosis
■ Missing the float from sensor
■ Disconnected Sensor Cable
■ Lower than Zero Position
3.6mA Current Out
■ Higher than Span Position
21mA Current Out
Simulation Current Out
■ 4mA @ 5 sec
■ 12mA @ 5 sec
■ 20mA @ 5 sec
Status Indicator
Bi-Color LED (Green/Red/Orange)
Zero / Span Set
Tact Switch
Wire Connection
One-Touch Connector
AWG 16 ~ 26
Ambient Temperature
-40℃ ~ +85℃
Dimension
80mm x 65mm x 20mm
Weight
54g
