Doc. no. :HTM-930 M_Kor_2016, Rev. 0
Issued date : 2016. 01
Page 3 / 7
1. Features
Can detect level of various solids and powders
Can be fully operated for powders of low and high densities.
Can detect the intrface of sediments in the liquid.
Has a longer lifetime since it has no mechanical movements.
Does not need adjustments after installation.
2. Specifications
Body Steel (SS41)
Protection IP65
Range of Environment Temp. -20°C ~ + 60°C
Mounting Material Stainless Steel (SUS 304)
Mounting Specification 3/4" PT (KSB0222)
Operating Temp.(Inside Vessel) -20°C ~ + 250°C
Max. Pressure 10 kgf/cm
2
Combination Unit HLC-901
Power Supply AC 110 V / 220 V 60 Hz± 10%
Power Consumption Approx. 5 VA
Sensitivity Over 0.2(Specific Gravity)
Max. AC 250 V, 5 A
Relay Output Max. DC 28 V, 5 A
(Relay 1 SPDT)
When relay is on.
Indication of Switch When detection LED is off.
When detection LED becomes RED.
Painting Metallic silver
Distance Between Sensor and unit Max. 300 m
Cable twisted paired cable
3. Operating Principle
HITROL’s HTM is an innovative, multipurpose switch and has the simplest structure.
HTM sensor head is composed of one module which has an oscillating coil generating frequency
and a sensing coil detecting oscillation.
When the material inside the vessel does not exist around the sensing rod, the sensing rod
continuously vibrates due to the oscillating coil.
