Hitron HM-90 Series User Manual

HM-30, 90 Series
HITROL CO., LTD. 4
Applications
Specification
■ Feedwater heater
■ Steam drum
■ Condensate drip pot
■ Flash tank
■ Separator
■ Receivers
■ Accumulator
Weather-Proof Version
Model
HM-30
HM-90
HM-90H
Installation
Top
Ambient Temperature
-20˚C ~ +80˚C
Process Temperature
Max.
-40˚C ~ +120˚C
Max.
-40˚C ~ +120˚C
Max.
-40˚C ~ +200˚C
-40˚C ~ +350˚C
-40˚C ~ +500˚C
Process Pressure
ATM
Up to 63kg/cm
2
(900#)
Contact Form
SPDT, DPDT
Enclosure
Weather-Proof (IP65)
Switch Type
Snap Switch, Hermetical Sealed Switch
Process Connection
50A JIS 10K FF(6T)
80A JIS 10K RF (Std.)
Material
Displacer
SUS 304 / SUS 316L
Chamber
N/A
C.S / SUS 304 / SUS316L / Others
Cable Entry
C.S; PF 3/4”(F) / AL; PF 3/4”(F) (Std.)
Ex-proof Version
Model
HM-90-Ex
HM-90H-Ex
Installation
Top
Ambient Temperature
-20˚C ~ +80˚C
Process Temperature
Max.
-40˚C ~ +120˚C
Max.
-40˚C ~ +200˚C
-40˚C ~ +300˚C
-40˚C ~ +350˚C
Process Pressure
Up to 63kg/cm
2
(900#)
Contact Form
SPDT, DPDT
Enclosure
Ex-Proof (Ex d IIC T4, IP65)
Switch Type
Snap Switch
Process Connection
80A JIS 10K RF (Std.)
Material
Displacer
SUS 304 / SUS 316L
Chamber
C.S / SUS 304 / SUS316L / Others
Cable Entry
AL; PF 3/4”(F) (Std.)
