Hiwin E1 Series Operation Procedure

Operation procedure for E1 series servo drive with absolute DM
1. Purpose
When E1 series servo drive is used with HIWIN absolute DM (DM□□□-A or DM□□□-B), users
have to follow the steps below to perform equipment confirmation and setting procedure.
Note: Motor models not listed in this document are not applicable to the operation procedure.
2. Equipment confirmation
 Applicable motor models, servo drive models and cables are shown as follows.
Table 2.1
Motor model
Resolution /
single turn
Servo drive model Motor power cable Encoder extension cable
DMN21-A
19 bit
ED1□-04□□-00
(400 W)
HVPS04AB□□MB HVE23IAB□□MB
DMN42-A
DMY44-B
20 bit
DMY48-B
DMN71-B
DMN93-B
DMY63-B
DMY65-B
DMY68-B
DMYA3-B
DMYA5-B
DMYAA-B
ED1□-10□□-00
(1 KW)
 Software version: Thunder 01.003.14
 Firmware version: Ver. 2.3.12

Hiwin E1 Series Specifications

General

Brand	Hiwin
Model	E1 Series
Category	Servo Drives
Language	English
