HK Audio CONTOUR ARRAY User Manual

5
A. Notes on Rigging Safety
Please read these instructions carefully before you begin setting up the system!
1.1 Intended Use
Specifications for intended use include the
following:
• When rigging enclosures, make sure that the load
is centered directly under the suspension point on
the rigging frame.
• The rigging frame may be tilted (not to be
confused with curved!) no more than 10% (6°).
Note that the specifications for intended use
require you to read and heed all of the operating
instructions and comply with inspection and
maintenance requirements.
Any use other than specified is unintended. The
manufacturer shall not be liable for damages
resulting from unintended use.
1.2 Unintended Use
Improper use of rigging frames and incorrect
handling of this load-carrying equipment can pose a
serious danger. Never
• use rigging frames to exert diagonal force or
tension on loads,
• use a crane to dislodge stuck or immovable loads,
• lift people,
• strike, knock or dent rigging frames,
• heat-treat or weld rigging frames,
• exceed the truss’s maximum load-carrying
capacity
Note that in addition to the above specifications,
the operational safety regulations of VBG 9
(accident prevention regulations of the German
employers’ liability insurance association) apply.
HK AUDIO is not responsible for damages caused
by improper use or non-compliance with setup and
operating safety specifications. HK AUDIO excludes
all warranty and liability claims for personal injury
and property damages attributable to one or several
of the following:
• non-compliance with manual’s instructions,
invalidating all product liability and
warranty claims
• unintended use of rigging frames
• non-compliance with operating manual
instructions on transport, storage, first setup,
operation, maintenance and repair
• unauthorized structural modifications performed
on rigging hardware
• unauthorized changes made to parameters
indicated in the operating manual
• inadequate or improper repairs
1 Use 2 Warranty and Liability
English

HK Audio CONTOUR ARRAY Specifications

General

Nominal impedance	8 Ohms
Model	CONTOUR ARRAY
Low/Mid Speaker	2x 8"
Connections	2 x NL4
Rigging points	Integrated rigging system
Dimensions (WxHxD)	40 cm

Summary

NOTES ON SAFETY FOR THE HK AUDIO CONTOUR ARRAY™

MAINTENANCE, INSPECTION AND REPAIR OF RIGGING HARDWARE

Regular inspections, maintenance, and authorized repairs are required for load-bearing equipment.

MAXIMUM NUMBER OF FLOWN ENCLOSURES

Fly no more than five (5) CTA 208 units in stacked array from a rigging frame.

PICK-POINTS FOR FLYING ENCLOSURES

Use rigging frame shackles for attaching motors/hoists. Clear the area below before lifting/lowering.

STRUCTURAL MODIFICATIONS OF RIGGING HARDWARE

INITIATION AND OPERATION

THE CTA 208 ENCLOSURES' TECHNICAL DATA

TECHNICAL DATA, CTA 118 SUB

RIGGING CONTOUR ARRAY™ ENCLOSURES

COMPONENTS AND APPLICATIONS OF RIGGING HARDWARE

Details components of rigging hardware: frame, shackles, quick-release pins, and their applications.

MOUNTING THE RIGGING FRAME

Step-by-step guide for mounting the rigging frame, involving two people and securing pins.

SETTING THE DUALCURVETM ANGLE

Instructions for setting the array curvature angle (0°, 3°, 6°, 9°) using the rear connector component.

RIGGING ADDITIONAL CTA 208 MID/HIGH ENCLOSURES

Procedure for rigging multiple CTA 208 units, involving attaching front/rear connectors and pins.

GROUND STACKING

Mount mid/high units individually

Procedure for stacking mid/high units on subwoofers using the stack plate for angle adjustment.

MAINS and GENERATOR POWER SUPPLY

Power connection limits

Power connection limits: max two CTA 118 Subs per 16A phase; generator use precautions.

THE CONTOUR ARRAY™ DDO-PRO™ CONTROLLER

AUDIO SIGNAL ROUTING

LEVEL

Adjusting input levels from -96 dB to +6 dB. Avoid Digital Clip by reducing console input level.

CONTROLLER FUNCTIONS AND SETTINGS

SUB DELAY

DELAY

SUB LEVEL

SERVICE

REPLACING 1", 8", AND 18" SPEAKERS

REPLACING DRIVERS' VOICE COILS

CHECKING SPEAKERS' PHASE
