HK Audio l.u.c.a.s alpha Service Documents

66606 St. Wendel / Germany
HK0206-EX-R04-1A-BASS-GESAMT
HK0206-LUCAS ALPHA
EXPLODED DRAWING COMPLETE
HK0206-EX-R04-1A
C. LORIS 2
Fehler: Keine Referenz
27.08.2007
A1
TITLE:
DRAWN BY:
PAGE:
DATE:
DRAWING-NO.:
VERSION:
REVISION:
CHECKED BY:
DATE:
MATERIAL:
FINISH:
FILENAME:
PAGES
INDEX CHANGES
RESP.
2
pos. no. part-no. 1 part-no. 2 description Beschreibung quantity
1 340144 front grille assembly Lucas Alpha sub Frontgitterbaugruppe Lucas Alpha Bass 1
2 400286 40 wooden cabinet Lucas Alpha sub 40 Holzgehäuse Lucas Alpha Bass 1
3 502203
(230-240V)
50 chassis Lucas Alpha sub 50 Chassis Lucas Alpha Bass 1
4 970851 sheet metal protection retainer 18'' Blech Schutzbügel 18'' 1
5 972008 damping wool Dämmwolle Hochbauschvlies 1
6 974011 hexagon socket head cap screw, M6x25, black Inbusschraube M6*25 sw 6
7 974020 hexagon socket head cap screw, M5x20, black Inbusschraube M5x20sw 6
8 974099 Mechanical locking screw, TENSILOCK W151, M6x20 Sperrzahnschraube M 6*20 vz, Tensilock W151 16
9 974108 plastic PCB spacer, 6.2x10x15, Polyamid black Dist.Hülse PE 6,2*10*15 [mm] 2
10 974220 hexagon socket countersunk head screw, M6x40, black Inbussenkschraube M6x40 sw 4
11 974233 washer, form A, D=6.4mm, zinc plated Unterleg-Scheibe 6,4 vz 2
12 974315 ABC-Spax-S screws for backwall, 4x50, black Rückwandschraube, 4*50 sw 2
13 974355 cross recessed panhead tapping screw with collar, 3.9x30,
black
Blechschr. KFR-Kopf 3,9* 30 sw 6
14 974454 plastic PCB spacer, 6.2x10x10, Polyamid black Dist.Hülse PE 6,2*10*10[mm] 2
15 974455 ABC-Spax-S chipboard screw, panhead Z, 5x16, black Pan Head-Z ABC-Spax sw 5*16 4
16 974475 hexagon socket head cap screw, M6x50, black Inbusschraube M6*50 sw 2
17 976009 rubber foot D38*H11 [mm] Gummifuss D38*H11 [mm] 4
18 976094 plastic dish 3403 HKBS! DART ! Griffschale 3403 HKBS! DART ! 2
19 976115 connector plate, M20 Befestigungsplatte M20 1
20 976158 castor 100mm, blue Lenkrolle 100mm, blau 4
21 976159 plastic dish Premium One Griffinnenschale Premium One 2
22* 982037 sealing tape 2x6mm Iso-Zell-Band fadenvers. 2*6mm 2,00 lfdm
23* 982078 sealing tape 2x20mm Iso-Zell-Band fadenvers. 2*20mm 1,40 lfdm
24* 986016 foam glue, Alfa D 4572 Klebstoff Alfa D 4572 xxx
25* 988208 Polyurethan Sabaflex 500 Polyurethan Sabaflex 500 xxx
26 994156 B&C 18 TBX100-4 TWS B&C 18 TBX100-4 TWS 1
