HK Audio l.u.c.a.s alpha Service Documents

66606 St. Wendel / Germany
HK0206-EX-R04-1A-BASS-CHASSIS
HK0206-LUCAS ALPHA
EXPLODED DRAWING CHASSIS
HK0206-EX-R04-1A
C. LORIS 2 24.08.2007
A1
TITLE:
DRAWN BY:
PAGE:
DATE:
DRAWING-NO.:
VERSION:
REVISION:
CHECKED BY:
DATE:
MATERIAL:
FINISH:
FILENAME:
PAGES
INDEX CHANGES
RESP.
3
pos. no. part-no. 1 part-no. 2 description Beschreibung quantity
1 547061 54 Preamp Lucas Alpha Sub 54 Preamp Lucas Alpha Bass 1
2 600080 Interfaceboard Deacon Interfaceboard Deacon 1
3 600087 mains filter Lucas Max 220-240V Netzfilt. Lucas Max 220-240V 1
4 600092 part of Input L+R Lucas Alpha sub assembly Teil von Nutzenplatine Input L+R Lucas Alpha
Bass
1
5 600092 part of Input L+R Lucas Alpha sub assembly Teil von Nutzenplatine Input L+R Lucas Alpha
Bass
1
6 600093 60 Sub Out Lucas Alpha sub 60 Sub Out Lucas Alpha Bass 1
7 931304 ferrite teroid core, 25x15x12 Ferritring, geschlossen 25x15x12 3
8 950055 Slide Switch 2xum T22205B Schiebeschalter 2xum T22205B 1
9 950060 hi-inrush, mains rocker switch, C13150VB Netzschalter gross C1350VB 1
10 952141 mains inlet PowerCon Netzbuchse Power Con Inlet 1
11 952305 speakon chassis connector, NL4MP-3 Speakonbuchse 4pol eckig, NL4MP-3 2
12 959052 PWM amp module 100-240V PWM Endstufe 100-240Volt 1
13 959068 QuadAMP, 4ch PWM unit, RD0303 QuadAMP, 4ch PWM Modul, RD0303 1
14 966046 plunger type key top, 9*9, B32-1210 Knopf-Taster 9*9 B32-1210 1
15 966075 Push-Bottom-Trio Knopf-Swtich TRIO 1
16 966076 softtouch poti knob, REAN, flexifit, F313 Knopf-Poti 13mm sw/sw/ws 3
17 970638 sheet metal Deacon cover panel Blech Deacon Abdeckplatte 1
18 970848 sheet metal Lucas Alpha chassis Blech Lucas Alpha Chassis 1
19 970849 sheet metal Lucas Alpha air guide Blech Lucas Alpha Lüftungshaube 1
20 970850 sheet metal Lucas Alpha foam holder Blech Lucas Alpha Schaumstoffhalter 2
21 970852 sheet metal Lucas Alpha support angle Blech Lucas Alpha Stützwinkel 1
22 972041 rubber punching 25x25x15mm Zellkaut. -Stanzteil 25x25x15mm 3
23 972086 acoustic grille foam, black 5mm Akustikschaum Anthrazit, 5mm 4
24 974007 hexagon socket oval head screw, M3x6, black Linsenschr.m.Innens. M3*6 sw 2
25 974075 cross recessed panhead screw, M3x5, zinc
plated
Linsenschraube M3x5 vz 2
pos. no. part-no. 1 part-no. 2 description Beschreibung quantity
26 974084 cross recessed panhead screw, M3x8, zinc
plated
Linsenschraube M3 x 8 vz 2
27 974100 toothed lock washer, D=3,2, AZ, black zinc
plated
Fächer-Scheibe az, 3,2 sw vz 6
28 974102 hexagon nut, class 8, M3, zinc plated Sechskantmutter M3 vz 2
29 974110 self locking hexagon nut with plastic insert,
M3, zinc plated
Stopmutter M3 vz 10
30 974135 spread rivet, polyamid PA6, 4x5, black PA-Spreizniet D=4mm L=5mm 8
31 974157 cross recessed raised countersunk tapping
screw, 2.9x9.5, black
Blechschr. Senk-Li 2,9*9,5 sw 10
32 974197 hexagon PCB spacer, type B, M3x8, zinc plated Dist. Bol Innen/Außengew. M3*8 vz 3
33 974228 cross recessed raised countersunk screw,
M3x10, black
Linsensenkschraube M3*10 sw 2
34 974290 self locking hexagon nut with plastic insert,
M4, zinc plated
Stopmutter M4 vz 9
35 974337 cross recessed countersunk screw, M3x6, zinc
plated
Senkschrauben M3*6 vz 2
36 974444 cross recessed raised countersunk screw,
M3x12, black
Linsensenkschraube M3*12 sw 2
37 974464 hexagon PCB spacer, type B, M3x13, zinc
plated
Dist. Bol Innen/Außengew. M3*13 vz 3
38 974521 cross rec. raised counters. tap. screw w.
cutting slot, 2.9x9.5, black
Senkschr. f. Kunststoff 2,9*9,5, sw 4
39 976007 cable tie 2,5x100 (mm) Kabelbinder natur 2,5x100 (mm) 9
40 976008 cable tie 2,6x200 (mm) Kabelbinder natur 2,6x200 (mm) 1
41 976135 socket for cable tie Schraubsockel 2
42 976141 rubberbuffer 15x15 B Gummipuffer GM-Puffer 15x15 B 8
43 976175 cable support "snap-in" Kabelhalter für Flachband 2
44* 988206 pre-cut part transfer tape 1573 Transferbandzuschnitt 1573 0,15 lfm
