9 Technical Specifications
L.U.C.A.S SMART Subwoofer
Inputs/Outputs:
Line In: XLR female, 1/4" combination jack
(pin 1= ground; 2= +, 3= -) electronically balanced &
floating
Aux In: RCA connector unbalanced
Mic In: XLR female (pin 1 = ground; 2 = +, 3 = -)
electronically balanced & floating
Sum Out, Master Out: RCA connector unbalanced
Output level: +4 dBV peak
Satellite speaker outs: Speakon
®
(pin 1+ = +, 1- = -)
Amplifier and loudspeakers Subwoofer
Subwoofer power output: 250 W / 3 ohms @ 0.3 % THD
Satellite power output: 2x 80 W / 4 ohms @ 0,3 % THD
Protection circuits: HK AUDIO
®
Multi Band Limiter,
Subsonic Filter
Low-frequency loudspeaker: 1x 10" HK AUDIO
®
Cus-
tom
Impedance: 3 ohms
Active crossover: 90 Hz; 24 dB/octave,
Frequency response: 43 Hz to 92 Hz, +/-3dB
34 Hz to 140 Hz, -10dB
Sound pressure level 1W/1m, half-space: 97 dB
Max. sound pressure level/1m, half-space: 117 dB @
10% THD
Weight: 21 kg/ 46.2 lbs.
Dimensions (WxHxD): 32 cm x 41 cm x 46,5 cm
(12-5/8" x 16-1/8" x 18-3/8")
L.U.C.A.S SMART Satellite
Loudspeaker input: Speakon
®
NL 4 (pin 1+ = +, 1- =
-)
Mid-range loudspeaker: 1x 6.5" HK AUDIO
®
Cus-
tom
Tweeter: 1x 1" Dome Tweeter
Mounting collar: HK AUDIO
®
MicroTilt™, 15 mm
Impedance: 4 ohms
Nominal power handling capacity: 80 W RMS
Crossover frequency (passive, internal): 3 kHz;
12 dB/octave
Frequency response (via active crossover): 92 Hz to
21 kHz, +/-3dB; 85 Hz to 23 kHz, -10dB
Sound pressure level 1W/1m, half-space: 97 dB
Max. sound pressure level/1m, half-space: 115 dB
@ 10% THD
Weight: 4.5 kg/9.9 lbs.
Dimensions (WxHxD): 18.5 cm x 27.5 cm
x 21.5 cm
(7-1/4" x 10-7/8" x 8-1/2")
General electrical data:
Protection class 1 (protectively earthed)
Mains fuse:
Version 230 V: 250 V / T 1.6 A
Version 120 V: 250 V / T 3.15 A
Version 100 V: 250 V / T 3.15 A
Max. power consumption: 370 VA
Mains voltage range: ± 10%
Ambient operating temperature: -10° C to +35° C
during operation
