HK Audio PULSAR PL 118 Sub A User Manual

Pulsar 1.0
8
5 Technical Specifi cations
Model PL 112 FA PL 115 FA PL 118 Sub A
Active x-over frequency 2.5 kHz, 24 dB / octave 2.5 kHz, 24 dB / octave 100 Hz / 120 Hz variable
with 24 dB / octave
Frequency response +/- 3 dB 70 Hz - 16 kHz 58 Hz - 16 kHz 44 Hz - X-Over
Frequency response -10 dB 56 Hz - 18 kHz 49 Hz - 18 kHz 35 Hz - X-Over
Max. SPL @ 10% THD 125 dB half space 127 dB half space 128 dB half space
Max. SPL peak @ 10% THD 131 dB half space 133 dB half space 125 dB half space
Max. SPL calculated 133 dB half space 135 dB half space 130 dB half space
Amp type Class D - biamped Class D - biamped Class D
Output power 1000 watts 1000 watts 600 watts
Amp to driver 350 W @ 4 ohms 350 W @ 4 ohms -
Amp to woofer 650 W @ 4 ohms 650 W @ 4 ohms 600 W @ 4 ohms
HF driver 1" 1" -
Bass woofer 12" featuring Advanced Cooling
Technology
15" featuring Advanced Cooling
Technology
18" featuring Advanced Cooling
Technology
Horn directivity 90° x 55° CD horn 90° x 55° CD horn -
Preamp DSP (time alignment) DSP (time alignment) Analog
Filter presets 2 EQ switches: Stand Alone /
System & Flat / Contour
2 EQ switches: Stand Alone /
System & Flat / Contour
-
Active protective circuits Under-voltage, thermal, short
circuit, over-current protection,
subsonic filter, look ahead
temperature control, peak, RMS
and multiband limiters
Under-voltage, thermal, short
circuit, over-current protection,
subsonic filter, look ahead
temperature control, peak, RMS
and multiband limiters
Under-voltage, thermal, short
circuit, and over-current
protection, look ahead
temperature control, peak limiter
Auto Standby Yes (defeatable) Yes (defeatable) Yes (defeatable)
Input sensitivity +4 dBu @ Gain center-notched +4 dBu @ Gain center-notched +4 dBu @ Gain center-notched
Audio ports 2x XLR Combo In, 1x Stereo RCA
In, 2 x XLR Thru, 1x XLR Mix Out
2x XLR Combo In, 1x Stereo
RCA In, 2x XLR Thru, 1x XLR
Mix Out
2x XLR Combo In, 2x XLR Thru,
2x XLR Mid/High Out
Mains connector 1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
1x IEC socket with V-Lock cord
retainer
Pole mount DuoTilt 3/7 DuoTilt 3/7 M20
Suspension points 5x M8 5x M8 -
Grips 2, integrated 2, integrated 4, integrated
Housing Hybrid (MDF, particle) Hybrid (MDF, particle) Hybrid (MDF, particle)
Front grille 1 mm metal grille backed with
black acoustic foam
1 mm metal grille backed with
black acoustic foam
1 mm metal grille backed with
black acoustic foam
Finish Black acrylic enamel Black acrylic enamel Black acrylic enamel
Casters - - Optional 100 mm
Power consumption 3 A / 220-240 V (6 A / 100-
120V) nominal according to
EN 60065
3 A / 220-240 V (6 A / 100-
120V) nominal according to
EN 60065
3 A / 220-240 V (6 A / 100-
120V) nominal according to
EN 60065
Optional accessories Cover, Tilt Unit, Rigging Yoke Cover, Tilt Unit, Rigging Yoke Cover, Mounting hardware for
casters, Tilt Unit
Dimensions (WxHxD) 38 x 66 x 37 cm
14-31/32 x 25-63/64 x 14-9/16"
46,5 x 69 x 45,2 cm
18-3/8 x 27-5/32 x 17-51/64"
52,5 x 69 x 69,1 cm
20-45/64 x 27-5/32 x 27-13/64"
Weight 19,7 kg / 43.4 lbs. 25,7 kg / 56.7 lbs 40,5 kg / 89.3 lbs
