OM-272 158 Page 4
SECTION 2 − SPECIFICATIONS
Cartridge Dimensions 4.53 x 5.2 x 0.39 in. (115 x 132 x 10 mm)
Viewing Field 3.82 x 2.36 in. (97 x 60 mm); 9.02 in
2
(58.2 cm
2
)
Reaction Time 0.000067 Second (1/15,000 Second)
Available Shades Darkened State: No. 8 − No. 13 / Light State: No. 3
Provides Continuous UV And IR Protection
Sensors Independent/Redundant (Four)
Operating Temperature 23F to 131F / −5C to +55C
When stored in extremely cold temperatures, warm
helmet to ambient temperature before welding.
Storage Temperature 14F to 158F / −10C to +70C
When stored in extremely cold temperatures, warm
helmet to ambient temperature before welding.
Power Supply CR2450 Lithium Batteries (2)
Total Weight 19.4 oz (550 g)
Standards ANSI Z87.1-2010 and DIN/CE/TUV/CSA
Warranty Two Years From Date Of Purchase (See Section 11)
Sensitivity/Grind Mode Control Adjusts For Varying Ambient Light And Welding Arc
Delay Control Slows Lens Dark-To-Light State Between 0.1 And
1.0 Seconds
Automatic Power Off Shuts Lens Off 15−20 Minutes After Welding Stops
Low Battery Indicator Red LED Illuminates To Indicate 2−3 Days Remaining
Battery Life
Work like a Pro!
Pros weld and cut
safely. Read the
safety rules at
the beginning
of this manual.
