OM-221 534 Page 10
SECTION 6 − REPLACING THE BATTERY
The XFS helmet has a non-replaceable Lithium battery.
1 XVS Auto-Darkening Lens
2 Battery Cover
Slide cover to left and remove batter-
ies. Install two AAA Alkaline batteries
and replace cover.
Be sure the positive (+) side of the
battery is aligned with positive (+)
terminal.
2
LOCKOPEN
AAA BATTERY
1
SECTION 7 − MAINTENANCE
NOTICE − Never use solvents or abrasive cleaning detergents.
NOTICE − Do not immerse the lens assembly in water.
The helmet requires little maintenance. However, for best performance clean
after each use. Using a soft cloth dampened with a mild soap and water solution,
wipe the cover lenses clean. Allow to air dry. Occasionally, the filter lens and
sensors should be cleaned by gently wiping with a soft, dry cloth.
