06-13
Small roof bonnet
To open the roof bonnet
• This roof bonnet can be opened to three
different settings in the opposite direction to
trafc. Press the locking knob on the side and
use the adjusting lever to move the roof bon-
net to the desired position; then click it into
place. The bonnet has a maximum opening
angle of 50°.
To close the roof bonnet
• Release the adjusting lever from its catch
position and close the roof bonnet. The bon-
net is automatically locked when it has been
completely closed.
