09-5
The external gas socket (optional) can be used
for connecting gas devices (such as the barbe-
que).
When hitching, the plug connection is plugged
into the safety coupling. The plug connection
can only be hitched when the emergency shutoff
valve
j
has been closed. Push back the clutch
sleeve to undo the safety latch.
9.3 External gas socket
1
• The operating pressure of devices to
be connected must be 30 mbar.
• Maximum performance of devices to
be connected: 1.5 kW
Shut the cap
k
of the valve opening
when the clutch is not in use.
2
