HOBBYEAGLE A3 PRO V2 User Manual

WWW.HOBBYEAGLE.COM 8 / 15
Setup Menu Table (* is the default setting)
Functions LED Status
Solid
Red
Solid
Green
Solid
Blue
Solid
Yellow
Solid
White
Solid
Violet
1
Wing Type White, 1 flash
Standard *
Delta-wing
V-Tail
2
Mount Orientation White, 2 flashes
Flat *
Flat
Inverted
Upright
Upright
Inverted
3
Flight Mode White, 3 flashes
1
Position-1 Blue, 1 flash
OFF *
NORMAL
LOCK
ANGLE
LEVEL
HOVER
2
Position-2 Blue, 2 flashes
OFF
NORMAL *
LOCK
ANGLE
LEVEL
HOVER
3
Position-3 Blue, 3 flashes
OFF
NORMAL
LOCK
ANGLE
LEVEL *
HOVER
4
Gyro Direction White, 4 flashes
1
Aileron Blue, 1 flash
Normal *
Reversed
2
Elevator Blue, 2 flashes
Normal *
Reversed
3
Rudder Blue, 3 flashes
Normal *
Reversed
5
Level Calibration White, 5 flashes
6
Hover Calibration White, 6 flashes
7
Maximum Angle White, 7 flashes
±30°
±60°*
±90°
8
Servo Frequency White, 8 flashes
50Hz *
65Hz
165Hz
200Hz
270Hz
333Hz
9
Gain Level White, 9 flashes
Small
Medium *
Large
10
Factory Reset White, 10 flashes
1. Wing Type
A3 Pro V2 supports standard fixed-wing, flying-wing (delta-
wing) and V-tail. After entering in this function, the color of
LED shows you the wing type currently selected. The
default setting is Standard (Red), each short press of the
button will switch to the next type. After you finish making
your selection, just wait for 5 seconds until LED starts blink
quickly which indicates that the modified is saved and then
you will be brought back to the Setup Menu level automatically. If you do not want to change anything,
just wait for timeout without any operation.
NOTES
 Make sure that there are no mixing functions active on your transmitter. Have a look at the
radio’s servo monitor and verify that each stick controls only one output channel.
 If two aileron servos are being used, please connect a Y-extended lead to [OUT1].
 Most flying-wings have no rudder, in this case, [RUD] is unnecessary to connect.
LED Color
Description
Solid Red
Standard (default)
Solid Green
Flying-wing (Delta-wing)
Solid Blue
V-Tail
