Program Table
1 2 3 4 5 6 7 8 9
Beep Codes
● = short
▬ = long
● ●● ●●● ●●●● ▬ ▬● ▬●● ▬●●● ▬●●●●
1 ● Running Mode Forward with Brake Forward/Reverse
with Brake
Rock Crawler
2 ●● Drag Brake Force 0% 5% 10% 20% 40% 60% 80% 100%
3 ●●● Low Voltage Cut-Off Threshold Non-Protected 2.6V/Cell 2.8V/Cell 3.0V 3.2V 3.4V
4 ●●●● Start Mode Level 1 (Soft) Level 2 L3 L4 L5 L6 L7 L8 L9
5 ▬ Maximum Brake Force 25% 50% 75% 100%
6 ▬● Maximum Reverse Force 25% 50% 75% 100%
7 ▬●● Initial Brake Force =Drag Brake Force 0% 20% 40%
8 ▬●●● Neutral Range 6% (Narrow) 9% (Normal) 12%
9 ▬●●●● Timing 0.00° 3.75° 7.50° 11.25° 15.00° 18.75° 22.50° 26.25°
10 ▬▬ Overheat Protection Enable Disable
