For the Advanced Setup, the Basic Setup must have been performed at least once!
1. Make sure that the ESC is off; switch on the transmitter with the throttle stick at full power.
2. Hold the Model, Connect the ESC with motor and battery => a monotonous continuous beep
should be heard.
3.
♪♪♪♪♪♪♪♪....: after approximately 20 tones, the advanced setup is activated as long as the
basic setup has been performed!
Acknowledgement
=> Advanced Setup
If the continuous beeps are not heard, please disconnect immediately the
battery from
the ESC and try again. Place the transmitter within range of the receiver if the antenna is
not extended.
In the advanced setup only ONE Menu option can be selected at a time, therefore the
main menu choice must take place first:
Place the stick again into full back position to select the main menu to modify:
Main Menu Options overview:
♪ Brake
♪♪
Battery-Type
♪ ♪ ♪ Timing
♪ ♪ ♪ ♪ PWM-Frequency
♪ ♪ ♪ ♪ ♪ Governor mode
Move the stick to full power after hearing the sounds for the desired parameter.
Acknowledgement:
♪ ♪
Note: If an
y parameter has not be selected, the menu will begin again with “Brake” and so on
(if selected), depending upon the selection now the ESC switches to the setting of the
Parameter. Possible (sub) menus:
1 Brake (
♪)
Brake selection
(Brake):
Move stick into full back position again
♪ No Brake
♪♪ Brake, Brake is activated if stick range has been configured accordingly.
Move the stick to full power to select the desired setting in the submenu. Acknowledgement:
♪ ♪
After the acknowledgement the menu option is programmed!
