Hobie Mirage Compass User Manual

17
hobie.com
Hole #1
1”
Choice for Hole #2
1
3/8” Left or right
2
3
Lowrance Ready Option
Wire Installation
Drill one 1” hole and one 1 3/8” hole using a hole saw in the areas
indicated. The forward hole can be drilled on the left or right.
Run cable into the
plug just in front of the
transducer scupper.
Lead the cable through the inside
of the hull and exit the cable
through the 3-way Thru-Hull Plug.
Hand tighten screws to avoid
stripping threads.
1

Hobie Mirage Compass Specifications

General

Fitted Hull Weight	68 lbs / 31 kg
Capacity	400 lbs / 181 kg
Hull Construction	Rotomolded Polyethylene
Seat	Vantage CT
Length	12 ft / 3.66 m
Width	34 in / 0.86 m
Storage	Front Hatch, Rear Cargo Area
Vantage Seat Capacity	275 lbs / 125 kg
