5-1. DC voltage (automatic range setting)
Range Resolution Accuracy
600 mV 0.1 mV ±(0.8% reading + 5 digits)
6 V 1 mV
±(0.8% reading + 3 digits)60 V 10 mV
600 V 100 mV
1000 V 1 V ±(1.0% reading + 5 digits)
Input impedance: 10 MΩ
Overload protection: 600 V DC/AC RMS
Max. Input voltage: 600 V DC
DVC 1000 V measurement according to CATII
5-2. AC voltage (automatic range selection)
Range Resolution Accuracy
600 mV 0.1 mV ±(1.2% reading + 8 digits)
6 V 1 mV
±(1.2% reading + 6 digits)60 V 10 mV
600 V 100 mV
750 V 1 V ±(1.2% reading + 8 digits)
Input impedance: 10 MΩ
Frequency range: 40 Hz ~ 400 Hz
Overload protection: 600 V DC / AC rms
Measurement of ACV 750 V in accordance with CATII CAT III
Max. Input voltage: 600 V AC RMS CATIII
5-3. TEMPERATURE
Range Resolution Accuracy
-20~1000°C 1°C
-40°C~150°C:±(1% + 4)
150°C~1370°C:±(2% + 3)
-4~1832°F 1°F
-40°F~302°F:±(5% + 4)
302°F~2000°F:±(2.5% + 3)
Overload protection: Fuse F0.4A / 600 V.
5-4. DC voltage
Range Resolution Accuracy
600 µA 0.1 µA
±(0.8% reading + 5 digits)
6000 µA 1 µA
60 mA 10 µA
600 mA 100 µA
6 A 1 mA
±(1.5% reading + 3 digits)
10 A 10 mA
Overload protection:
Socket „mA”: fuse F0.4A / 600 V.
Socket „10A”: fuse F10A / 600 V.
