13
Adres producenta/ Adresse des Herstellers/ Manufacturer’s Address/ Адрес производителя
GTV Poland Sp. z o.o. Sp. k., ul. Przejazdowa 21, 05-800 Pruszków
Max. Output current: Socket „mA”: 600mA, Socket „10A”: 10A
(For measurements> 5A: duration <10 seconds, interval> 15 minutes)
A drop in voltage: 600µA, 60mA: 60mV,
Ranges 6000µA, 600mA and 10A: 600mV
5-5. hFE transistor test (connect adapter)
Range hFE Amperage test Voltage test
PNP& NPN 0~1000 Ib≈2µA Vce≈1V
5-6. AC CURRENT
Range Resolution Accuracy
600 µA 0.1 µA
±(1.5% reading +8 digits)
6000 µA 1 µA
60 mA 10 µA
600 mA 100 µA
10 A 100 mA ±(2.0% reading +10 digits)
Overload protection:
Socket „mA”: fuse F0.4A / 600 V.
Socket „10A”: fuse F10A / 600V Max.
Output current:
Socket „mA”: 400mA
Socket „10A”: 10A
(For measurements> 5A: duration <10 seconds, interval> 15 minutes)
A drop in voltage:
Range 600µA, 60mA: 60mV
Ranges 6000µA, 600mA and 10A: 600mV
Frequency range: 40 Hz ~ 400 Hz
5-7. Resistance (automatic range selection)
Range Resolution Accuracy
600 Ω 0.1 Ω
±(1.5% reading + 3 digits)
6 KΩ 1 Ω
60 KΩ 10 Ω
600 KΩ 100 Ω
6 MΩ 1 KΩ
60 MΩ 10 KΩ ±(1.5% reading + 5 digits)
Open circuit voltage: about 0.25 V.
Overload protection: 250 V DC / AC RMS
5-8. PAC 600A current through pliers
Range Resolution Accuracy
600A 1mV/10A
±(2.5%+10)
200A 1mV/1A
