Holley pro-jection 2D - 4.0 ADDITIONAL ITEMS REQUIRED FOR INSTALLATION; 5.0 TOOLS REQUIRED FOR INSTALLATION

Item 19 Item 20 Item 21
Item 22 Item 23 Item 24
Item 25 Item 26 Item 27
Item 28 Item 29 Item 30
Item 31 Item 32
4.0 ADDITIONAL ITEMS REQUIRED FOR INSTALLATION
• more 3/8” Marine fuel hose marked U.S.C.G. Type A1 (if needed) • more 5/16” Marine fuel hose marked U.S.C.G.
• 5/16” US Coast Guard approved seamless metallic fuel line T
ype A1 (if needed)
• 0-30 psig fuel gauge • Tee fitting for fuel gauge
In addition to the above list, the boat’s engine must be equipped w
ith a four barrel intake manifold, there must be adequate hatch
clearance (1" taller than stock) and the boat’s engine and electrical system must be in good operating condition.
5.0 TOOLS REQUIRED FOR INSTALLATION
• 1/2" Socket and Wrench • Small blade standard screwdriver • 5/32” Allen wrench
• Medium blade standard screwdriver • #2 Phillips screw
driver • Digital Volt-Ohm meter
• Drill and assorted bit sizes • Hole saw (2”) • T
erminal crimping tool
• Engine tachometer • To
rque wrench • Utility knife
• 12 volt test light
An assistant is necessary for some installation and adjustment procedures and should be present for safety reasons. If y
ou
don't have a test light, we would suggest that you purchase one for use in this installation.
