2
=Power
=Mode Section
=Heating on half power (1000W)
=Heating on full power (2000W)
P = Weekly programming
=Open window Mode
°C = Setting temperature
= swing
= Timer (Turn-on/Turn-off)
Installation:
Drill two holes in wall and have a distance of 2.05m from the ground. The diameter of
the hole just contained the inflated plastic pipe. After tucked the inflated plastic pipe,
fixed pothook on the pipe with screw. Make sure pothook fastness and hang the
heater. The clip under the pothook should be inserted rabbet of the heater bottom.
Installation:
ON-OFF
- Press the ON -OFF switch to switch the appliance ON (I) or OFF (O).
Stand-by mode
FAN and HEATING (by control panel)
- Press the button to select one of the following mode
Stops by going into standby Fan without heating Heating on half power
(the fan stops 30 seconds
after the stand-by).
EN
