PACKING LIST
ROWING MACHINE COMPONENTS
PARTS LISTS
1.Frame 2.Front foot pipe
3.Rail 4.Frame connection
6.Lock bolt set x 25.Front rail cover 7.Seat 8.Rear support
14.Left pedal13.Long sleeve x 2
15.Right pedal 16.Pedal pipe x 2
10.Rear rail cover
9.Connecting sheet
11.Rear foot pipe 12.Short sleeve x 2
17.M10*55mm
Allen bolt x 2
22.M8 split washer x 8
27.M12 lock nut 28.Detent pin
29.Knob bolt
30.M8*20mm
hex bolt x 4
31.Big M8 flat
washer x 4
32.Allen wrench x 2 33.Open end wrench x 4
23.M5*16mm bolt
24.M10*55mm
carriage bolt x 2
25.M10 acorn nut x 2
26.M12*100mm
hex bolt
18.M10 flat washer x 4
19.M10 split washer x 2
20.M8*16mm
Allen bolt x 8
21.M8 flat washer x 8
（13*15mm）
（17*19mm）
