~ 9 ~
Step 7: Installation of the up raising control part:
• Fix the gourd buckles (27) on the two ends when using the cable (V). The gourd buckle connects
the shoulder rest (U) and the cable (V).
• Fix the angle of the backrest with the popper pin (26).
CARE AND MAINTENANCE
1. Regularly examine the equipment to detect any damage to wear which may have occurred.
The safety level of the equipment can be maintained only if it is examined regularly for
damage and wear and tear on ropes, pulleys, and connection points.
2. Lubricate moving parts with light oil periodically to prevent premature wear.
3. Inspect and tighten all parts before using the equipment. Replace defective components
immediately and/or keep the equipment out of use until repair. Pay particular attention to
components most susceptible to wear.
4. The equipment can be cleaned using a soft, damp cloth. Do not use solvents or abrasive
cleaners.
