Homelite CSP 3314 - PARTS User Manual

Position Article-no Description Qty Price w/o tax
4 BM_UP04056 HANDGUARD SPRING 1 € 0,51
5 BM_UP04202 PIVOT, L.H. 1 € 2,06
6 BM_UP04201 PIVOT, R.H. 1 € 2,06
7 BM_UP04240 SCREW (8-32 X 5/8 IN.) 1 € 0,66
8 N/A GUIDE BAR BOLT [ ENGINE HOUSING ... CHASSIS ASSEMBLY ... ] 2
9 BM_UP04206 GUIDE BAR PLATE 1 € 1,18
10 BM_UP04085 GUIDE BAR PLATE 1 € 1,18
11 BM_UP04082 SCREW (6-19 X 1/2 IN.) 1 € 2,25
12 BM_985030001 BRAKE BAND 1 € 1,95
13 BM_UP04181 ROLL PIN 1 € 1,87
14 BM_985021001 CHAIN BRAKE COVER 1 € 0,40
15 BM_UP08000A ADJUSTING PIN 1 € 3,85
16 BM_UP04239 SCREW (8-19 X .320) 3 € 0,50
17 BM_984897001 CHAIN BRAKE LINK 1 € 9,15
18 BM_UP04090 ROLL PIN 1 € 2,44
19 BM_UP04182 THRUST WASHER 1 € 1,69
20 BM_984898001 CLUTCH & HARDWARE 1 € 17,60
21 BM_984350001 DRUM SPROCKET (.375 PITCH) 1 € 7,45
22 BM_PS04669 NEEDLE BEARING 1 € 5,05
23 BM_UP04228 RETAINING RING 1 € 0,16
24 BM_UP04179 CUPPED WASHER 1 € 1,03
25 BM_PA01106 DRIVE CASE COVER ASSEMBLY 1 € 3,50
26 BM_PS02928 CHAIN CATCHER 1 € 0,41
27 BM_UP03897 SCREW (10-24 X 1/2 IN.) 1 € 0,07
28 BM_UP04058 HEX NUT 2 € 2,47
29 BM_985240001 COMPRESSION SPRING 1 € 0,80
Position Article-no Description Qty Price w/o tax
1 BM_06870 REAR HANDLE 1 € 4,20
2 BM_UP04234 SCREW (12-14 X 1-1/2 IN.) 2 € 0,84
3 BM_984354002 THROTTLE TRIGGER 1 € 1,00
4 BM_PS06283 THROTTLE LOCK OUT 1 € 0,95
5 BM_06871 HANDLE COVER 1 € 1,56
6 BM_UP03900 SCREW (10-14 X 3/4 IN.) 2 € 2,25
7 BM_PS06281 THROTTLE PIN LOCK 1 € 0,25
8 BM_UP04238 SCREW (10-14 X 1- 3/8 IN.) 1 € 1,13
9 BM_08898 SPRING 1 € 0,75
10 BM_UP04050 E-RING 1 € 0,25
11 BM_PS03985 FRONT HANDLE 1 € 3,25
12 BM_07384 ISOLATOR PLATE 1 € 0,35
13 BM_UP04237 SCREW (10-14 X 5/8 IN.) 3 € 1,03
14 BM_UP04233 SCREW (10-24 X 5/8 IN.) 1 € 0,66
15 BM_UP04200 LIMITER, ISOLATOR 1 € 1,87
16 BM_UP03897 SCREW (10-14 X 1/2 IN.) 3 € 0,07
17 BM_UP04218 THROTTLE CABLE 1 € 5,16
18 BM_PS05217 EXTENSION SPRING 2 € 4,72
19 BM_PS05199 UPPER ISOLATION SPRING 1 € 0,30
Position Article-no Description Qty Price w/o tax
BM_09207 UNIVERSAL WRENCH COMBINATION 1 € 7,35
BM_UP06563 SCABBARD [ 4206103 ] 1 € 8,00
AB_080006 GUIDE BAR 14" (35CM) 1 € 38,50
AB_080011 CHAIN 14" (35CM / 3/8") 1 € 20,50
RQ* ... ON REQUEST NLA* ... NO LONGER AVAILABLE TBO* ... TO BE OBSOLETE
PRICES ARE SUBJECT TO CHANGE WITHOUT NOTICE
handles
CSP 3314 < ACCESSORIES >
15.02.2005 3 / 3 RYOBI SERVICE DEPT.
