Homelite CSP 3314 - PARTS User Manual

Position Article-no Description Qty Price w/o tax
8 BM_984891001 CARBURETOR 1 € 37,00
9 BM_UP04094 CARBURETOR GASKET 1 € 2,25
10 BM_07589 FLANGE NUT (10-24) 2 € 0,66
11 BM_UP04218 THROTTLE CABLE 1 € 5,16
12 BM_UP04184 GASKET, HEAT DAM 1 € 0,71
13 BM_UP04173 HEAT DAM 1 € 9,74
14 BM_UP04191 SEAL, HEAT DAM 1 € 1,03
15 BM_UP04084 SCREW, TRUSS HD. (10-24 X 7/8 IN.) 2 € 0,21
16 BM_UP04189 SCREW, CARBURETOR 2 € 0,43
17 BM_07454 FUEL LINE (TANK TO CARB. 8-1/2 IN.) 1 TBO
18 BM_07454 FUEL LINE (CARB. TO PURGE BULB. 8 IN.) 1 TBO
19 BM_UP04171
CARBURETOR GROMMET
1 € 3,03
20 BM_UP04533 AIR FILTER COVER 1 € 5,91
21 BM_PS05070 PRE FILTER (IN ENGINE HOUSING) 1 € 0,15
22 BM_UP04235 SCREW, SLOTTED PAN HD. (8-16 X 5/8 IN.) 2 € 0,66
23 BM_PS06280 ROD, CHOKE 1 € 1,00
24 BM_UP04178 AIR FILTER PLATE 1 € 4,31
25 BM_UP04227 SPRING CLIP (CHOKE ROD) 1 € 0,66
26 BM_UP04825 SPARK PLUG 1 € 5,69
27 BM_PA01396 OIL PUMP ASSEMBLY 1 € 9,11
28 BM_PA01037 OIL INTAKE W/FILTER 1 € 1,20
29 BM_UP03897 SCREW, THD. FORMING (10 -14 X .5) 1 € 0,07
30 BM_UP03867 WASHER, RETAINING 1 € 2,25
Position Article-no Description Qty Price w/o tax
1 BM_06875 CYLINDER COVER 1 € 14,43
2 BM_UP04219 SCREW-SLOTTED PAN HEAD 3 € 0,43
3 BM_PS03503 CONTROL PANEL 1 € 0,40
4 BM_PS06280 CHOKE ROD 1 € 1,00
5 BM_UP04218 THROTTLE CABLE 1 € 5,16
6 BM_UP04197 ROCKER SWITCH 1 € 2,29
7 BM_UP04215 SPLIT GROMMET 2 € 0,46
8 BM_UP04033 PRIMER BULB 1 € 3,60
9 BM_07454 RUBBER TUBING (5-1/2 IN.) 1 TBO
10 BM_985029 CHASSIS ASSEMBLY 1 € 61,00
11 N/A FILTER ELEMENT (BRONZE) 2
12 N/A DUCK BILL VALVE 2
13 N/A OIL OUTLET GROMMET 1
14 BM_PA01037 OIL INTAKE TUBE, W/FILTER 1 € 1,20
15 BM_07454 RUBBER TUBING 8-1/2 IN.) 1 TBO
16 BM_PS03380 FUEL FILTER 1 € 0,70
17 N/A FUEL CAP, W/RETAINER 1
18 N/A OIL CAP, W/RETAINER 1
X N/A GUIDE BAR BOLT (NOT SHOWN) 2
19 N/A OIL FILTER 1
20 BM_UP04221 SPEED NUT (U-TYPE) 3 € 0,66
21 BM_UP04083 SCREW, (10-24 X 2 IN.) 4 € 5,33
22 BM_UP04087 WASHER 4 € 2,25
23 BM_PS05070 PRE FILTER 1 € 0,15
24 BM_UP04215 SPLIT GROMMET 1 € 0,46
25 BM_UP04052 GROMMET 1 € 2,47
Position Article-no Description Qty Price w/o tax
1 BM_PS04726 HAND GUARD 1 € 6,10
2 BM_07580 HAND GUARD ACTUATING PIN 1 € 0,93
3 BM_UP04056 RETAINING RING 1 € 0,51
