HOMELITE gEnEraTOr − HgCa3000 sErIEs
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
107 310757001 Fan ....................................................................................1
108 310758001 Flywheel ............................................................................1
109 678281002 Governor Arm ....................................................................1
110 678361002 Link Rod ............................................................................1
111 678363002 Carburetor Spring .............................................................1
112 678280002 Spring ................................................................................1
113 678342002 Fan Case ...........................................................................1
114 310760001 Air Cleaner Assembly (Incl. Key Nos. 115-119) ................1
115 521508001 Air Filter Case ....................................................................1
116 638344002 Plate ..................................................................................1
117 638345002 Element Fitting Plate .........................................................1
118 310764001 Air Filter Element ...............................................................1
119 521509001 Air Filter Cover ..................................................................1
120 940707081 Warning Label ...................................................................1
121 660972015 Screw (M6 x 20 mm) .........................................................2
122 310733002 Oil Cap/Dipstick ................................................................1
123 660972004 Screw (M6 x 12 mm, Fillister Hd.) .....................................2
124 678460005 Nut (M6) .............................................................................2
125 678727004 Nut (M16, Flange Hd.) .......................................................1
126 678370008 Washer ..............................................................................1
127 310755002 Ignition Module .................................................................1
128 940515016 CPSC Label .......................................................................1
129 940707080 Danger Label (FR) .............................................................1
130 570418001 Warm Air Tube Hypotheca ................................................1
131 570419001 Warm Air Tube Epitheca ....................................................1
132 661536001 Bolt (ST4.8*16) .................................................................1
133 519721004 Connector .........................................................................1
134 570740004 Gasket 5 ............................................................................2
135 678519003 Spring ................................................................................1
136 678522009 Cotter Pin ..........................................................................1
137 638344004 Valve Plate .........................................................................1
138 678740001 Rocker ...............................................................................1
139 678739001 ElasticNut(ST４.8) ..............................................................2
NOT SHOWN:
987000583 Operator’s Manual .............................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY.
NOTE A: Homelite Consumer Products, Inc., will not provide engines as replacement parts.
Engines are covered through the engine manufacturer’s warranty. Consult the accompanying
engine manual or contact our service department for assistance.
WARNING:
To avoid possible personal injury or equipment damage, a registered electrician or an authorized
service representative should perform installation and all service. Under no circumstances should
an unqualified person attempt to wire into a utility circuit.
The model number will be found on a plate attached to the engine. Always mention the model number in all correspondence regarding your GENERATOR
or when ordering replacement parts.
