Engine specifications
Engine model DJ1P70F
Engine type 4-stroke Air- cooled
OHV
Bore and stroke 70 mm / 45 mm
Displacement 173 cc
Starting system Recoil
Fuel type Automobile Gasoline
Unleaded
Fuel tank capacity (l) 0.8
Lubrication oil type Automobile Oil
10W-30, Class SE
or higher
Engine oil capacity (l) 0.6
Noise specifications
Uncertainty (dB) 2
Noise level LpA dB (A) 92
Noise level LwA dB (A) 106
Vibration level
Uncertainty K = 0.5 m/s
2
Vibration level ah = 2.7 m/s
2
INTENDED USE
You may use this tool for the purposes listed below:
■ Removing dirt and mold from decks, cement patios,
and house siding.
■ Cleaning boats, outdoor furniture, and grills
FEATURES
KNOW YOUR PRESSURE WASHER
See gure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
FUEL TANK
This fuel tank has a maximum capacity of 0.8l. Use
unleaded automotive fuel in the engine.
HOSE STORAGE
Once the high pressure hose is rolled, hang it on the back
of the machine using the hook-and-loop strap to secure
in place.
ON/OFF SWITCH
The on/off switch is used in combination with the starter
grip and rope to start the engine. It is also used to turn
the engine off.
STARTER GRIP WITH ROPE
The starter grip with rope is pulled to start the machine.
SPARK ARRESTOR
This engine is factory equipped with a spark arrestor. In
some areas it is illegal to operate an engine without a
spark arrestor.
THERMAL RELIEF VALVE
This pump feature will prevent water temperatures from
reaching harmful levels by releasing a small amount of
water. Once the water has drained, the thermal relief valve
will reset itself.
TRIGGER HANDLE
The trigger handle has a gripping surface that provides
added control of the spray wand and helps reduce fatigue.
TRIGGER WITH LOCK OUT
Pulling the trigger releases a stream of water for high
pressure cleaning. The lock out provides protection
against unauthorised use.
DESCRIPTION
1. Fuel tank
2. Oil cap/ dIpstick
3. High Pressure hose
4. Nozzles and nozzle storage
5. Fuel cap
6. Handle
7. Trigger handle
8. Lock out
9. Trigger
10. Recoil starter
11. ON/OFF switch
12. Spray wand
13. Injection hose
14. Funnel
15. Injection hose tting
16. Injection hose lter
17. Connector
18. Collar
19. Inlet coupler
20. Threaded nipple
21. Water intake
22. Screen
23. Garden hose
24. Start
25. Choke lever
