HOMELITE 46cc CHAIN SAW – MODEL No. UT10519, UT10522, UT10526
PARTS LIST
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 310508002 Chain Cover Assembly .................................................. 1
2 310629001 Guide Bar (20 in. with SAFE-T-TIP)
— UT10522, UT10526 ................................................... 1
310628001 Guide Bar (18 in. with SAFE-T-TIP)
— UT10519.................................................................... 1
3 511709012 Choke Lever .................................................................. 1
4 760338001 Ignition Switch ............................................................... 1
5 T660619001 Screw (6-19 x 1/2 in. T.F.) .............................................. 1
6 660636001 Screw (10-16 x 1-1/2 in. Special) .................................. 3
7 518042010 Top Cover ...................................................................... 1
8 660617001 Screw (8-16 x 16 mm Torx T.F.) ..................................... 1
9 518049002 Air Filter Cover ............................................................... 1
10 870174001 Spark Plug (Champion RCJ6Y) ..................................... 1
11 660625001 Screw (10-24 x 5/8 in. Torx Pan Hd.) ............................. 1
12 518055002 Fan Housing Baffle ........................................................ 1
13 308067004 Starter Cover Assembly ................................................. 1
14 660632001 Screw (10-14 x 5/8 in. Torx Pan Hd.) ............................. 4
15 300948002 Fuel Cap Assembly ........................................................ 1
16 300949002 Oil Cap Assembly .......................................................... 1
17 660624001 Screw (8-32 x 5/16 in.) ................................................... 1
18 638467002 Muffler Deflector ............................................................ 1
19 638673001 Spark Screen ................................................................. 1
20 309310001 Muffler Assembly (Includes Key Nos. 17-19) ................. 1
21 671079001 Lock Nut (10-32) ............................................................ 3
22 660626002 Muffler Bolt (Square Hd.) ............................................... 3
23 631055001 Combination Wrench (UT10526 only) ............................ 1
24 900920027 Chain (.325 x 78 link, 20 in.) — UT10522, UT10526 ..... 1
901430001 Chain (.325 x 72 link, 18 in.) — UT10519 ...................... 1
25 638455001 Heat Shield .................................................................... 1
26 900844001 Pre-Filter ........................................................................ 1
27 631036001 Inner Guide Plate ........................................................... 1
28 671103001 E-Ring ............................................................................ 1
29 631060001 Cupped Washer ............................................................. 1
30 300958002 Sprocket Drum and Bearing Assembly (.325 chain) ...... 1
31 631039001 Spike Bar ....................................................................... 1
32 678027002 Lock Nut (10-24) ............................................................ 1
33 300759005 Fuel Filter ....................................................................... 1
34 631035001 Chain Catcher ................................................................ 1
35 900894001 Muffler Gasket ............................................................... 1
36 660629001 Screw (10-14 x 3/4 in.) ................................................... 2
NOT SHOWN
518061001 Scabbard .................................................................... 1
987000393 Operator’s Manual (960970013) ................................. 1
8-6-10
(Rev:06)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
