HOMELITE 46cc CHAIN SAW – MODEL No. UT10519, UT10522, UT10526
PARTS LIST (FIGURE A)
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 700106001 Heat Reflector Tape .................................................... 1
2 671087001 Spacer Insert .............................................................. 4
3 570226001 Oil Outlet Grommet .................................................... 1
4 660503002 Guide Bar Bolt (M8 x 1-1/4 in.) ................................... 1
5 671077001 Speed Nut (“U”-type) ................................................ 2
6 560955001 Duck Bill Valve ............................................................ 2
7 671088001 Element ...................................................................... 2
8 671080001 Washer ....................................................................... 4
9 660622001 Screw (10-24 x 2 in.) ................................................... 4
10 690765001 Hose Clamp ................................................................ 1
11 300951015 Chassis Assembly ...................................................... 1
12 671077002 Speed Nut (“U”-type) ................................................ 1
13 570259046 Return Line (175 mm) ................................................. 1
14 570259034 Fuel Line (230 mm) ..................................................... 1
15 638024001 Spring ......................................................................... 1
16 671075001 Retaining Ring ............................................................ 1
17 511723111 Hand guard, Gray ....................................................... 1
18 620282001 Handguard Actuating Pin ........................................... 1
19 631063002 Brake Band ................................................................. 1
20 671095001 Spring Pin ................................................................... 1
21 678113001 Spring ......................................................................... 1
22 511720002 Chain Brake Cover ..................................................... 1
23 660634001 Screw (8-16 x 5/16 in.) ............................................... 3
24 300954001 Chain Brake Link Assembly ....................................... 1
25 671099001 Spring Pin (Small) ....................................................... 1
26 660635001 Screw (8-32 x 5/8 in.) ................................................. 1
27 671096001 Pivot (Right Hand) ...................................................... 1
28 671097001 Pivot (Left Hand) ......................................................... 1
29 631034002 Hair Pin ....................................................................... 1
30 900885001 Throttle Cable ............................................................. 1
31 308088001 Primer Bulb ................................................................. 1
32 570259051 Primer Line (64 mm) ................................................... 1
33 570227001 Split Grommet ............................................................ 1
34 518044012 Control Panel, Gray .................................................... 1
35 511724011 Front Handle, Gray ..................................................... 1
36 660631001 Screw (12-14 x 1-1/2 in.) ............................................ 1
37 511721014 Rear Handle, Gray ...................................................... 1
38 671101001 Extension Spring ........................................................ 2
39 660632001 Screw (10-14 x 5/8 in.) ............................................... 2
40 660618001 Screw (10-14 x 1/2 in.) ............................................... 3
41 518051013 Lockout Throttle, Black .............................................. 1
42 660629001 Screw (10-14 x 3/4 in.) ............................................... 2
43 660719001 Screw (10-14 Thread Twin Helix) ................................ 1
44 631050001 Spring Retainer ........................................................... 1
45 660633001 Screw (10-14 x 1-3/8 in.) ............................................ 1
46 511722013 Handle Cover, Gray .................................................... 1
47 678037001 Torsion Ring ................................................................ 1
48 518052011 Trigger, Black .............................................................. 1
49 518050011 Plug, Gray ................................................................... 1
50 631051001 Isolator Plate .............................................................. 1
51 671098001 Isolator Spring ............................................................ 1
52 660630001 Screw (10-24 x 5/8 in.) ............................................... 1
53 660639001 Screw (8-32 x 5/8 in.) ................................................. 2
54 290195003 Ignition Switch Harness ............................................. 1
55 300953001 Ignition Kit .................................................................. 1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
