HOMELITE 16 in. 33cc CHAIN SAW – MODEL NUMBERS UT10532
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 671076001 Guide Bar Nut (5/16-18) ................................... 2
2 308006001 SAFE-T-TIP ....................................................... 1
3 308625001 Guide Bar (16 in.) (Incl. Key Nos. 2 and 5) ........
1
4 308116002 Guide Bar Adjustment Assembly .....................
1
5 660640001 SAFE-T-TIP (Screw and Washer) ......................
1
6 638173001 Outer Guide Plate .............................................
1
7 T660619001 * Screw (6-19 x 1/2 in. T.F.) ................................. 2
8 660636001 * Screw (10-16 x 1-1/2 in. Special) .....................
3
9 518238001 Top Cover ......................................................... 1
10 660617001 * Screw (8-16 x 16 mm Torx T.F.) ........................ 2
11 518306001 Air Filter Cover .................................................. 1
12 870174001 Spark Plug (Champion RCJ6Y) ........................ 1
13 660868001 * Screw (10-24 x 5/8 in. Torx Pan Hd.) ................ 1
14 518283001 Baffle ................................................................ 1
15 308382001 Starter Cover Assembly .................................... 1
16 660632001 * Screw (10-14 x 5/8 in. Torx Pan Hd.) ................ 6
17 308362001 Fuel Cap Assembly ........................................... 1
18 308363001 Oil Cap Assembly ............................................. 1
19 660624001 * Screw (8-32 x 5/16 in.) ..................................... 2
20 638148001 Plate .................................................................. 1
21 638147001 Spark Screen .................................................... 1
22 300940005 Muffler Assembly (Incl. Key Nos. 19-21) .......... 1
23 671079001 * Lock Nut (10-32) ............................................... 3
24 660765001 * Bolt (10-32 x 63.6 mm Square Hd.) .................. 3
25 308369001 Combination Wrench ........................................ 1
26 901383001 Chain ................................................................ 1
27 308364001 Chain Cover Assembly ..................................... 1
28 900844002 Pre-Filter ........................................................... 1
29 638169001 Inner Guide Plate .............................................. 1
30 671103001 E-Ring ............................................................... 1
31 631060001 Cupped Washer ................................................ 1
32 300958001 Sprocket Drum & Bearing Assembly ................. 1
33 638176001 Bumper Spike ....................................................1
34 678744002 * Lock Nut (10-24) ............................................... 1
35 300759003 Fuel Filter .......................................................... 1
36 631035001 Chain Guard ..................................................... 1
37 120640001 Tool Holder Assembly ....................................... 1
38 638041002 Heat Shield ....................................................... 1
39 900977003 Muffler Gasket ....................................................1
40 940717001 Starter Housing Decal ........................................1
41 940635001 Clutch Cover Label .............................................1
42 940634001 Chain Brake Label ..............................................1
43 940637001 Warning Label .....................................................1
44 940632001 Starting Instruction Decal ...................................1
45 940964002 Icon Warning Label .............................................1
46 638381001 Heat Shield .........................................................1
580656001 Scabbard (Not Shown) ..................................... 1
983000735 Operator’s Manual (961027001)
983000735R Repair Sheet (Rev:01)
07-28-06
KEY PART
NO. NUMBER DESCRIPTION QTY
