Homelite UT10532 Repair Sheet

HOMELITE 16 in. 33cc CHAIN SAW – MODEL NUMBERS UT10532
5
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 901358001 Heat Reflector Tape ............................................1
2 660632001 * Screw (10-14 X 5/8 in. Torx Pan Hd.) ................
8
3 671075001 Retaining Ring ....................................................
1
4 660635001 * Screw (8-32 X 5/8 in. Hex Soc. Hd.) ...................
1
5 620442001 Handguard Lever Pin ..........................................
1
6 671096001 Pivot (Right Hand) ...............................................
1
7 518278001 Handguard ..........................................................
1
8 671097001 Pivot (Left Hand) .................................................
1
9 638024001 Spring .................................................................
1
10 300954002 Chain Brake Link Assembly ................................1
11 671099001 Roll Pin (Small) ....................................................1
12 940636001 On-board Label ..................................................1
13 570247007 Rubber Tubing (120 mm) ....................................1
14 660634002 * Screw (8-16 X 17 mm) ........................................1
15 678113001 Spring .................................................................1
16 660634001 * Screw (8-16 X 0.32 Pan Hd.) ..............................3
17 518305001 Brake Band Cover ..............................................1
18 671095001 Roll Pin (Big) .......................................................1
19 671087001 Spacer Insert ......................................................4
20 631063001 Chain Brake Band Kit .........................................1
21 660964001 * Screw (10-24 X 19.5 mm) ...................................2
22 678744002 * Lock Nut (10-24) ................................................2
23 671077001 Speed Nut (“U”-type) .........................................3
24 660628001 Guide Bar Bolt ....................................................2
25 631034001 Spring Clip ..........................................................1
26 518298001 Choke Rod ..........................................................1
27 570219001 Grommet .............................................................1
28 300780002 Primer Assembly ................................................1
29 900885002 Throttle Cable .....................................................1
30 570227001 Split Grommet ....................................................2
31 760338001 Switch .................................................................1
32 518276001 Control Panel ......................................................1
33 308823001 Chassis Assembly (Inc. Key Nos. 10, 11, 14-20,
23, 24, 50 and 53) ...............................................
1
34 671080001 Washer ................................................................4
35 660622001 * Screw (10-24 X 2 in. Soc. Cap Hd.) ....................4
36 660630001 * Screw (10-24 X 5/8 in. Torx Hd.) .........................1
37 518244001 Front Handle .......................................................1
38 671100003 Upper Isolator Spring .........................................1
39 631051001 Isolator Plate .......................................................1
40 518240001 Handle Support ..................................................1
41 518301001 Lockout Throttle .................................................1
42 678037001 Torsion Spring .....................................................1
43 308776001 Isolator Limiter ....................................................2
44 671100002 Isolator Spring ....................................................2
45 518300001 Trigger .................................................................1
46 671073001 Spring .................................................................1
47 518241001 Handle Cover ......................................................1
48 518299001 Throttle Lock Pin ................................................1
49 638177001 Retaining Ring ....................................................1
50 671088001 Element ...............................................................2
51 290709001 Lead, Ignition Wire ..............................................1
52 660792001 * Screw (9-15 x 1 in.) .............................................2
53 560955001 Duck Bill Valve ....................................................2
54 678399001 Washer ................................................................2
55 290709002 Lead, Ground Wire .............................................1
56 638394001 Slotware for Lead ...............................................1
57 570247006 Rubber Tubing (95 mm) ......................................1
58 300953002 Ignition Module ...................................................1
59 570247008 Rubber Tubing (222 mm) ....................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
