HOMELITE 16 in. 33cc CHAIN SAW – MODEL NUMBERS UT10532
7
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
1 640941004 Cylinder ......................................................................................................................
1
2 678181001 Piston Ring .................................................................................................................1
3 671078001 Wire Clamp .................................................................................................................1
4 570661001 Intake Boot Rubber ....................................................................................................1
5 518490001 Carburetor Plate .........................................................................................................1
6 660879001 * Screw (10-24 x 2-1/4 in.) ............................................................................................2
7 300945001 Oil Pump Assembly ....................................................................................................1
8 678183001 Retaining Ring ............................................................................................................2
9 570597001 Oil Outlet Grommet ....................................................................................................1
10 640974002 Piston (33cc) ..............................................................................................................1
11 660632001 * Screw (10-14 x 5/8 in. Torx Pan Hd.) ........................................................................4
12 518245001 Carburetor Spacer ......................................................................................................1
13 T610389001 Left Hand Worm .........................................................................................................1
14 570577001 Spacer Seal ...............................................................................................................1
15 631061001 Thrust Washer ............................................................................................................1
16 300960003 Clutch Assembly ........................................................................................................1
17 308290001 Crankshaft Assembly .................................................................................................1
18 900843001 Carburetor Gasket ......................................................................................................1
19 518312001 Carburetor Grommet ..................................................................................................1
20 300981002 Carburetor Assembly .................................................................................................1
21 518360001 Air Filter Plate .............................................................................................................1
22 678033001 * Flange Nut (10-24) ......................................................................................................2
23 308291001 Oil Intake Tube with Spring ........................................................................................1
24 308007001 Bearing Case with Bearing .........................................................................................2
25 640957001 Crankcase ..................................................................................................................1
26 660627001 * Screw (8-32 X 5/8 in. Pan Hd.) ...................................................................................2
27 678123001 * Nut (5/16-24) ..............................................................................................................1
28 631049001 Flat Washer ................................................................................................................1
29 308631001 Rotor Assembly ..........................................................................................................1
30 570220001 Shaft Seal ...................................................................................................................2
31 620391001 Piston Pin ...................................................................................................................1
32 300984003 Short Block Assembly (Inc. Key Nos. 1, 2, 8, 10, 17, 24, 25, 30 and 31) ..................1
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
