HOMELITE 35cc/38cc/42cc CHAIN SAWS
MODEL NOs. UT10548, UT10568, UT10588
PARTS LIST (FIGURE C)
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
CHAIN SAW or when ordering repair parts.
1 310550003 Oil Tank & Cap Assembly
(Inc. Key Nos. 8-9 and 38) .......................................... 1
2 310551004 Fuel Tank & Cap Assembly
(Inc. Key Nos. 10-12 and 18) ...................................... 1
3 660609001 Screw (M5 x 28 mm) .................................................. 4
4 518760001 Choke Lever ............................................................... 1
5 300780003 Primer Bulb ................................................................. 1
6 570259048 Primer Bulb Inlet Tube (73 mm) .................................. 1
7 760338002 Switch ......................................................................... 1
8 671090001 Cone Spring ............................................................... 1
9 570097001 Oil Pump Inlet Tube .................................................... 1
10 570259040 Fuel Line Inlet (Helical) ................................................ 1
11 570259055 Fuel Line (205 mm) ..................................................... 1
12 300759005 Fuel Filter .................................................................... 1
13 660503003 Guide Bar Bolt (5/16-18) ............................................ 2
14 310501004 Main Chassis .............................................................. 1
15 309643007 Engine Assembly ........................................................ 1
16 518756001 Front Hand Guard ....................................................... 1
17 678602001 Hand Guard Insert ...................................................... 1
18 690765001 Hose Clamp ................................................................ 1
19 678063001 Oil Pump Gear Spring ................................................ 1
20 570096001 Oil Pump Outlet Tube ................................................. 1
21 638504001 Thrust Washer ............................................................ 1
22 310510001 Clutch Assembly ........................................................ 1
23 660610001 Screw (M4 x 9.5 mm) ................................................. 2
24 309514001 Oil Pump Assembly .................................................... 1
25 678054001 Chain Brake Pin .......................................................... 1
26 678061001 Spring ......................................................................... 1
27 678060001 Chain Break Pivot ....................................................... 1
28 671075001 E-Ring ......................................................................... 1
29 671099001 Spring Pin ................................................................... 2
30 660608001 Screw (M4 x 12 mm) .................................................. 7
31 638502001 Brake Band ................................................................. 1
32 678058001 Chain Brake Linkage .................................................. 1
33 518754001 Spring Guide .............................................................. 1
34 671095001 Spring Pin ................................................................... 1
35 671077003 Speed Nut (“U”-Type) ................................................ 2
36 678057001 Chain Brake Spring .................................................... 1
37 518819001 Chain Brake Cover ..................................................... 1
38 580506001 Oil Tank ....................................................................... 1
39 518755003 Rear Handle ................................................................ 1
40 660630001 Screw (10-24 x 5/8 in.) ............................................... 1
41 678069001 Isolator Spring ............................................................ 3
42 660614001 Screw (10-14 x 16 mm) .............................................. 5
43 901654001 Anti-Vibe Strap ........................................................... 1
44 570095001 Isolator ........................................................................ 2
45 518765002 Trigger ......................................................................... 1
46 518764001 Lock-Out Lever ........................................................... 1
47 678068001 Trigger Return Spring ................................................. 1
48 518763001 Rear Handle Cover ..................................................... 1
49 678603001 Throttle Rod ................................................................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
