17
120693
oWNeR’S MANUAl
For more information, visit www.desatech.com
PARTS lIST
UT13130
This list contains replaceable parts used in your chainsaw. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
KEY PART
NO. NO. DESCRIPTION QTY.
1 14SB Guide Bar, 14" 1
2 14SC Saw Chain 1
3 107481-01 Armature Assembly 1
4 075676 Sprocket Roller Bearing 1
5 107319-01 Hex-Head Bolt 2
6 107512-01 Cap & Bulb Assembly 1
7 099829-01 Cord 1
8 077399-14 Side Cover, Black 1
9 076105 Thrust Disk 1
10 107482-01 Field & Brush Assembly 1
11 059606 Drive Gear 1
12 107713-01 Internal Gear 1
13 106809-02 Front Hand Guard 1
14 079089-07 Motor Housing, Black 1
15 NPC-4C Hex Nut 2
16 077115 Adjusting Plate Assembly 1
17 075887 Bearing Plate 1
18 079086-02 Oil Reservoir 1
19 097403-01 Pan-Head Screw 1
20 108120-01 E-Ring 1
21 076906 Flat-Head Tap Screw 2
22 107708-01 Pan-Head Tap Screw 10
23 077143 Sprocket Support 1
24 077525S Lock-Off Switch 1
25 106810-01 Sprocket Cover, Black 1
26 079963-04 Scabbard 1
