Homelite UT32600 Repair Sheet

7
HOMELITE 26cc STRING TRIMMERS – MODEL NUMBERS UT32600 AND UT32650
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 660466001 Screw (M4 x 18 mm) ........................................11
2 660970001 Screw (M4 x 16 mm) ..........................................4
3 310829001 Front Housing Assembly ...................................1
4 511731001 Pulley Handle .....................................................1
5 660968001 Screw (M4 x 19 mm) ..........................................2
6 850108009 Ignition Module ..................................................1
7 660638003 Screw (10-24 x 2-3/16 in.) .................................2
8 638442001 Heat Shield ........................................................1
9 308990016 Muffler Assembly ...............................................1
10 901452011 Muffler Gasket ...................................................1
11 308892006 Short Block Assembly .......................................1
12 519824001 Rear Housing .....................................................1
13 901551001 Intake Gasket .....................................................1
14 518497001 Heat Dam ...........................................................1
15 521808001 Heat Dam Deflector ...........................................1
16 901552001 Carburetor Gasket .............................................1
17 308054001 Carburetor .........................................................1
18 521806001 Air Box Base ......................................................1
19 660454010 Screw (M5 x 79 mm) ..........................................2
20 521608001 Choke Plate .......................................................1
21 660970002 Screw (M4 x 10 mm Shoulder) ..........................3
22 308675001 Fuel Tank Assembly w/Cap ...............................1
23 308811006 Flywheel Assembly ............................................1
24 650017001 Washer ...............................................................1
25 901552002 Carburetor Gasket ............................................1
26 638389001 Pulley Retainer ...................................................3
27 310022004 Starter Pulley Assembly .....................................1
28 638033001 Spring & Container Assembly ............................1
29 518692001 Starter Housing .................................................1
30 638284006 Spacer Tube ......................................................1
31 638090001 Clutch Washer ...................................................1
32 300960002 Clutch Assembly ................................................1
33 308863001 Lead Assembly ..................................................1
34 901550001 Gasket ...............................................................1
35 638337001 Crankcase Cover ...............................................1
36 660925003 Screw (M4 x 12 mm) ..........................................6
37 900849002 Starter Rope (42 in.) ..........................................1
38 521807001 Choke Lever ......................................................1
39 561635001 Primer Bulb ........................................................1
40 690969001 Washer ...............................................................1
41 679018001 Curved Washer ..................................................1
42 660345001 Screw (M4 x 12 mm) ..........................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE C)
