7
HOMELITE 26cc STRING TRIMMERS – MODEL NUMBERS UT32601, UT32605, UT32601A and UT32605A
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 660466001 Screw (M4 x 18 mm) ..........................................11
2 660970001 Screw (M4 x 16 mm) ............................................4
3 310829001 Front Housing Assembly ......................................1
4 511731001 Pulley Handle .......................................................1
5 660968001 Screw (M4 x 19 mm) ............................................2
6 850108009 Ignition Module .....................................................1
7 660638003 Screw (10-24 x 2-3/16 in.) ....................................2
8 638442001 Heat Shield ...........................................................1
9 308990016 Muffler Assembly (Non “A” versions) ...................1
300748027 Muffler Assembly (“A” versions) ...........................1
10 901452011 Muffler Gasket ......................................................1
11 308892006 Short Block Assembly ..........................................1
12 519824001 Rear Housing ........................................................1
13 901551001 Intake Gasket .......................................................1
14 518497001 Heat Dam .............................................................1
15 521808001 Heat Dam Deflector ..............................................1
16 901552001 Carburetor Gasket ................................................1
17 308054043 Carburetor Assembly ...........................................1
18 518766001 Air Box Base .........................................................1
19 660454007 Screw (M5 x 79 mm) ............................................2
20 561635001 Primer Bulb ..........................................................1
21 660970002 Screw (M4 x 10 mm Shoulder) .............................3
22 308675001 Fuel Tank Assembly w/Cap .................................. 1
23 308811006 Flywheel Assembly ............................................... 1
24 650017001 Washer .................................................................1
25 900849002 Starter Rope (42 in.) ............................................1
26 638389001 Pulley Retainer .....................................................3
27 310022004 Starter Pulley Assembly .......................................1
28 638033001 Spring & Container Assembly ..............................1
29 518692001 Starter Housing ...................................................1
30 638284006 Spacer Tube .........................................................1
31 638090001 Clutch Washer ......................................................1
32 300960002 Clutch Assembly ..................................................1
33 308863032 Lead Assembly ..................................................... 1
34 901550001 Gasket ..................................................................1
35 638337001 Crankcase Cover .................................................. 1
36 660925003 Screw (M4 x 12 mm) ............................................6
37 521523001 Choke Lever .........................................................1
38 300759005 Fuel Filter .............................................................. 1
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE C)
