FEATURES
KNOW YOUR CHAIN SAW
See Figure 6.
The safe use of this product requires an under-
standing of the information on the tool and in
this operator’s manual as well as a knowledge
of the project you are attempting. Before use of
this product, familiarize yourself with all operating
features and safety rules.
CHAIN TENSIONING KNOB
This feature allows user to adjust the tension of
the chain.
GUIDE BAR
The factory-equipped guide bar has a small
radius tip that offers a somewhat lower kickback
potential.
LOW KICKBACK SAW CHAIN
The low kickback saw chain helps minimize the
force of a kickback reaction by preventing the
cutters from digging in too deeply at the kickback
zone.
QUICK VIEW OIL INDICATOR
Semi-transparent oil reservoir that allows user to
see when to add oil.
SAFE-T-TIP
®
ANTI-KICKBACK NOSE
GUARD
The Safe-T-Tip® Anti-Kickback Nose Guard is an
attach-ment provided on the end of the guide bar
to prevent the chain on the end of the guide bar
from contacting the wood.
SWITCH LOCK-OUT
A control feature designed to prevent the motor
from being accidently started.
SWITCH TRIGGER
Squeeze the switch trigger to operate the unit after
switch lock-out has been pushed in. Release the
switch trigger to stop the unit.
