A - Bottom cover (couvercle inférieur, tapa inferior)
B - Latch (loquet, broche)
C - To unlock bottom cover and disable motor (to unlock bottom cover and disable motor, to unlock
bottom cover and disable motor)
D - To lock bottom cover and reconnect motor (To lock bottom cover and reconnect motor, To lock
bottom cover and reconnect motor)
E - Blade assembly (ensemble lame, hoja)
Fig. 5 Fig. 6
Fig. 7
A
A - Scabbard (fourreau, funda)
Fig. 8
A
B
C
A - Screws (vis, tornillos)
B - Motor housing cover (carter du moteur,
cubierta de la caja del motor)
C - Battery pack (bloc-piles, paquete de
baterías)
D - Leads (fils, conductores)
E - Wire cutters with rubber coated or insulated
handles (coupe-fils doté d’un revêtement en
caoutchouc ou de poignées isolées, fresas
de alambre con mangos revestidos de hule
o aislados)
D
E
A
A
E
B
D
C
B
