Homemaker FD-40M - Fan Components Identification

Page 5 of 10
2 Components
A Grille Decoration M Neck
B
Front Grille
N
Post
C
Locking Clip
O
Height Adjustment Knob
D
Fan Blade
P
Base
E
Fan Blade Locking Screw
Q
Weight
F
Rear Grille Screws
R
Washer
G
Rear Grille
S
Locking Lever
H
Carry Handle
T
Tilt Range Knob
I
Motor Spindle
U
Tilt Range Screw
J
On / Off / Speed Knob
V
Tilt Range Screw Slot
K Oscillating Knob W Tilt Adjustment Knob
L
Motor Housing
X
Tilt Adjustment Bolt
