Homentry HERDO1 - Partial Opening Feature (PET)

11
B
E
E
P
A
UDIBLE BEEP (OPTIONAL)
DN UP PS
1
23
132A2940
Flash
x
2
AUDIBLE
BEEP
Flash x 2
B
E
E
P
DNDN
UPUP PP
SS
1
1
22
33
The HERDO1 has been factory set for Audible
“BEEP”.
T
he Audible beep can be turned OFF by using the
following method.
• Start with the door fully CLOSED.
• Press and Hold both “S” and “DN” buttons
for 3 seconds
•
The Courtesy light will flash “TWICE”.
Release Buttons.
To turn the audible beep back ON, simply repeat the
above process.
1
7
Door Fully Closed
fig.1
fig.2
fig.3
B
EEP
DNDN
UPUP PP
SS
11
22
33
Flash
x 1
B
EE
P
DNDN
UPUP PP
SS
11
22
33
Flash
x 2
This is an adjustable, second stop position suitable for
ventilation, pedestrian or pet access, programmed to the
Remote Control.
NOTE: Wireless Wall buttons will not operate this feature.
To Activate the Partial Opening Feature:
1.Start with the door fully CLOSED (figure 1). Drive the
opener UP and stop at the position required for PET access.
2.Enter PET activation mode by pressing the P and UP
buttons together for 3 seconds (figure 2). Release when the
Courtesy light flashes once.
3.Press the Remote Control button that you have allocated for
this feature (figure 3). Do not use the button already
allocated for normal operation. The Courtesy light will flash
when the code is accepted.
The remote will now operate to and from the “programmed” and
the “fully closed position”. Outside this range the remote will
operate as normal.
To Deactivate the Partial Opening Feature:
1.Start with the door fully CLOSED.
2.Enter PET Activation mode by pressing the P and UP
buttons together for 3 seconds (figure 2). The Courtesy light
will flash twice, indicating that deactivation has occurred.
PARTIAL OPENING FEATURE (PET)
18
