6
LEFT / RIGHT HAND INSTALLATION
11
LEFT
(handing must
be changed
during limit
setting)
RIGHT
(factory
default
setting)
Inside garage looking out
PINNING THE DOOR
N
ote: A ballooning door may delay the safety reversal
response and can compromise garage door security.
• To remedy any ballooning, insert the supplied self tapping
m
etal screws (inset 3) into where the curtain leaves the roll.
Secure these through the curtain into the drum wheel at
each end of the roll.
• After determining the correct fastener location as shown, lift
t
he door approximately half a turn from the closed position
to allow access for securing the screws.
Free curtain
Ballooning
Add fasteners here
Door closed
Door can be
lifted
Door secure
1
0
