If equipped
Use a wrench to remove the
mounting bolt from the underbody.
Pull the under cover away from
the bumper.
Remove the electrical connector
from the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Insert the new bulb into the
assembly and turn it one-quarter
turn clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Reinstall the mounting bolt on the
under cover.
1.
4.
5.
3.
2.
6.
7.
Lights
ReplacingaFogLightBulb
Maintenance
257
BOLT
BULB
CONNECTOR
０７／０５／０９ １１：４８：０８ ３１Ｓ９Ｖ６５０ ０２６２
