Open the tailgate.
Remove the two screws, then pull
the rear light assembly straight
back to remove it from the body.
Open the tailgate. Place a cloth on
the edge of the cover. Remove the
covers by carefully prying on the
edge with a small flat-tip
screwdriver.
Remove the socket by turning it
one-quarter turn counterclockwise.
Remove the socket of the burned
out bulb by turning it one-quarter
turn counterclockwise, and pull it
straight out of its socket.
Install a new bulb into the socket,
and reinstall the socket into the
light assembly.
1.1.
2.
3.
2.
4.
Lights
Replacing Rear Bulbs Replacing a Back-up Light Bulb
258
SCREW
SCREW
BULB
SOCKET
BULB
SOCKET
０７／０５／０９ １１：４８：１７ ３１Ｓ９Ｖ６５０ ０２６３
