14/02/18 12:54:32
01) 11-14 Odyssey MMC SM-A 14 61TK830Z enu
NOTE: The air intake duct and the front bulkhead cover are removed in the illustrations.
Unit: mm (in)
C
F
A, a
Bulkhead Upper Center Frame A
Locating Hole ø20 (0.78)
B, b
Front Fender Bracket Mounting
Bolt (Center of the bolt)
C
F
C
F
A
B
C
a
b
c
C, c
Front Fender Rear Mounting
Bolt (Center of the bolt)
1644
(64.72)
1322
(52.05)
802
(31.57)
435
(17.13)
1460
(57.48)
1082
(42.60)
Upper Body Measuring Dimensions
Front Fender Positions
4-2
4495_3.0_enu_10319398_3.0
