Honda 2012 Odyssey Body Repair Manual

14/02/18 12:54:32
01) 11-14 Odyssey MMC SM-A 14 61TK830Z enu
Unit: mm (in)
F1, f1
Sliding Door Sub-Seal
Mounting Hole ø5 (0.20)
F
F
F
F1
F2
F3
1737
(68.39)
1429
(56.26)
1848
(72.76)
F4
Sliding Door Center Rail
Mounting Hole ø6.3 (0.248)
F2, f2
Sliding Door Upper Female Guide
Mounting Hole ø10 (0.39) upper
f1
f2
f3
F4
F5
f5
C
C
C
F3, f3
Sliding Door Lower Female Guide
Mounting Hole ø10 (0.39) upper
C
F
F5, f5
Sliding Door Rear Striker
Mounting Hole
14 (0.55) x 14 (0.55) square
1802
(70.94)
1097
(43.19)
1118
(44.02)
1188
(46.77)
982
(38.66)
1183
(46.57)
1040
(40.94)
Upper Body Measuring Dimensions
Sliding Door Female Guide and Striker Positions
4-8
4531_3.0_enu_10319404_3.0
