Electrical Trouble
u
Blown Fuse
84
Blown Fuse
Before handling fuses, see “Inspecting and
Replacing Fuses.”
2
P. 46
❙
Fuse Box Fuses
1.
Remove the battery cover.
2
P. 54
2.
Pull the fuses out with the fuse puller in
back side of battery cover one by one
check for blown fuse. Always replace a
blown fuse with a spare of the same
rating.
u Spare fuses are provided back side of
the battery cover.
3.
Install the battery cover.
Battery cover
Spare fuses
Main fuse
Fuse puller
If a fuse fails repeatedly, you likely have an electrical
problem. Have your scooter inspected by your dealer.
16 ACG110CBT (PH)-32K20C200.book 84 ページ ２０１５年６月３０日 火曜日 午後２時２３分
To Next Page
