Honda CB300F 2014 User Manual

61
Maintenance
Side Stand
1. Check that the side stand operates
smoothly. If the side stand is stiff or
squeaky, clean the pivot area and
lubricate the pivot bolt with clean grease.
2. Check the spring for damage or loss of
tension.
3. Sit on the motorcycle, put the
transmission in Neutral, and raise the side
stand.
4. Start the engine, pull the clutch lever in,
and shift the transmission into gear.
5. Lower the side stand all the way. The
engine should stop as you lower the side
stand. If the engine doesn’t stop, have
your motorcycle inspected by your dealer.
Side stand spring
15 CB300FA (U)-32K33K000.book 61 ページ ２０１４年１０月９日 木曜日 午後１時４分
Honda CB300F and CB300FA Owner's Manaul
http://www.motorcycle.in.th

Honda CB300F 2014 Specifications

General

Engine Type	286cc liquid-cooled single-cylinder four-stroke
Displacement	286cc
Cooling System	Liquid-cooled
Transmission	6-speed
Rear Suspension	Pro-Link single shock
Rear Brake	Single 220mm disc
Front Tire	110/70-17
Rear Tire	140/70-17
Seat Height	30.7 inches
Fuel Capacity	3.4 gallons
Curb Weight	348 pounds
Bore x Stroke	76mm x 63mm
Compression Ratio	10.7:1
Ignition	Computer-controlled digital transistorized with electronic advance
Wheelbase	54.3 inches
Final Drive	O-ring-sealed chain
Fuel System	PGM-FI, 38mm throttle body
Front Suspension	37mm fork
Front Brake	Single 296mm disc
Rear Suspension Adjustability	Preload
