Honda CBR600RR 2009 User Manual

179
Transporting Your Motorcycle
Tips
If your motorcycle needs to be transported,
it should be carried on a motorcycle trailer,
or a truck or trailer with a flatbed area. Do
not tow your motorcycle, as towing can
seriously damage the transmission.
When contacting a towing or transporting
service, be sure to ask if they have a
flatbed area, a loading ramp or power
ramp to safely lift the motorcycle, and
motorcycle tie-down straps.
０８／０９／１９ ２０：５８：４６ ３１ＭＦＪ６２０ ０１８８

Honda CBR600RR 2009 Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Induction	Dual Stage Fuel Injection (DSFI)
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	#525 O-ring-sealed chain
Front Suspension	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Wheelbase	53.9 inches
Rake	23.5 degrees
Seat Height	32.3 inches
Fuel Capacity	4.8 gallons
Curb Weight	410 pounds
Transmission	Six-speed
Trail	3.8 inches
