Honda CBR600RR 2009 User Manual

366 lbs (166 kg)
31 lbs (14 kg)
375 lbs (170 kg)
(Canada only)
49
Loading GuidelinesLoad Limits
Load Limits & Guidelines
Before Riding
maximum weight capacity:
maximum cargo weight:
Your motorcycle is primarily intended for
transporting you and a passenger. You
may wish to secure a jacket or other small
items to the seat when you are not riding
with a passenger.
If you wish to carry more cargo, check
with your Honda dealer for advice, and be
sure to read the information regarding
accessories on page .
Following are the load limits for your
motorcycle:
includes the weight of the rider,
passenger, all cargo, and all accessories.
Improperly loading your motorcycle can
affect its stability and handling. Even if
your motorcycle is properly loaded, you
should ride at reduced speeds and never
exceed 80 mph (130 km/h) when carrying
cargo.
The weight of added accessories will
reduce the maximum cargo weight you
can carry.
5
０８／０９／１９ ２０：４２：５７ ３１ＭＦＪ６２０ ００５８

Honda CBR600RR 2009 Specifications

General

Engine Type	599cc liquid-cooled inline four-cylinder
Bore x Stroke	67.0mm x 42.5mm
Compression Ratio	12.2:1
Induction	Dual Stage Fuel Injection (DSFI)
Ignition	Computer-controlled digital transistorized with 3-D mapping
Final Drive	#525 O-ring-sealed chain
Front Suspension	41mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability; 4.7 inches travel
Rear Suspension	Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability; 5.1 inches travel
Front Brake	Dual radial-mounted four-piston calipers with 310mm discs
Rear Brake	Single 220mm disc
Front Tire	120/70ZR-17 radial
Rear Tire	180/55ZR-17 radial
Wheelbase	53.9 inches
Rake	23.5 degrees
Seat Height	32.3 inches
Fuel Capacity	4.8 gallons
Curb Weight	410 pounds
Transmission	Six-speed
Trail	3.8 inches
